Hunan Yibeinuo New Material Co., Ltd. jest producentem ceramicznych produktów odpornych na ścieranie i niestandardowych rozwiązań w zakresie ochrony przed zużyciem przemysłowym. Pod marką Elacera oferujemy rury wykładane ceramiką, wykładziny gumowo-ceramiczne, elementy ceramiczne z tlenku glinu oraz niestandardowe rozwiązania w zakresie ochrony przed zużyciem dla górnictwa, cementu, energetyki, hutnictwa, portów i systemów pneumatycznego transportu.Kim JesteśmyHunan Yibeinuo New Material Co., ...
Ucz się więcej

0

Rok utworzenia

0

Milion+
Pracownicy

0

Milion+
obsługiwanych klientów

0

Milion+
Roczna sprzedaż
Chiny Hunan Yibeinuo New Material Co., Ltd. Kontrola jakości
Przed pakowaniem i wysyłką sprawdzane są surowce, gęstość ceramiki, wymiary i gotowe produkty.
Chiny Hunan Yibeinuo New Material Co., Ltd. INŻYNIERIA NA ZAMÓWIENIE
Okładziny ceramiczne są dostosowywane do rysunków, wymiarów urządzeń, materiałów i rzeczywistych warunków pracy.
Chiny Hunan Yibeinuo New Material Co., Ltd. Niezawodna produkcja
Stabilne procesy produkcyjne i doświadczeni technicy pomagają zapewnić stałą jakość i terminowość dostaw.
Chiny Hunan Yibeinuo New Material Co., Ltd. Szybkie działanie
Ocenę w ciągu 12 godzin Zapewnij rozwiązania anty-nadzorcze 24 godziny na dobę. Wygodne kanały dostawy: samochód, pociąg, samolot, transport morski itp.

Jakość Odporna na zużycie rura ceramiczna & otulina ceramicznego koła pasowego Producent

Znajdź produkty, które lepiej spełniają Twoje wymagania.
Sprawy i wiadomości
Najnowsze Hot Spoty.
DN80 95% Alumina Ceramic Ring Lined Elbows for Germany
ELACERA supplied two DN80 ceramic ring-lined elbows with 95% alumina ceramic lining for a customer in Germany. The elbows featured a 90° bend, an R500 radius, and loose flange connections. The customer's order, placed in December 2021, included a drawing reference, the bend geometry, and the flange arrangement. These details defined the configuration for this two-piece supply. Supply Details Item Supply Details Quantity 20 elbows Nominal size DN80 Bend angle 90° Bend radius R500 mm Ceramic lining material 95% alumina Lining structure Ceramic ring lining Flange arrangement Two loose flanges per elbow Flange reference DIN 2642, as specified in the original order Matching the Ceramic Lining to the Complete Elbow For a ceramic ring-lined elbow, material selection and dimensional matching need to be reviewed together. The ceramic forms the internal wear-contact surface, while the steel shell provides the outer structure and supports the connections. The drawing review should cover the finished bore, ceramic thickness, transitions between ceramic sections, and lining termination at both ends. The flange dimensions and the mating pipeline also need to be checked together. For a replacement enquiry, these details help establish whether the proposed elbow will fit the available installation space and connect correctly to the adjoining pipework. From Finished Elbows to Export Packing The pre-packing photographs show the two finished elbows with grey-white exterior surfaces and protective covers secured over the openings. Both curved assemblies and their flange connections are visible before wrapping. The packing photographs then show the elbows individually wrapped and placed side by side inside a wooden case. The wrapping covers the curved bodies and end connections. The case exterior carried handling marks for upright positioning, keeping dry and fragile cargo. Together, the photographs record the products before packing, their arrangement inside the case, and the closed case before dispatch. When planning a similar shipment, the complete assembly weight, projecting connections, support and restraint all deserve attention alongside surface protection. Enquiries for Similar Ceramic Ring Lined Elbows For a similar requirement, send ELACERA the drawing, required finished bore, ceramic thickness, bend angle and radius, and flange details. Please also include the conveyed material, operating temperature, pressure, and any available photographs of existing wear. This information helps us review the lining structure and connection requirements for the intended application.
Why Do Ceramic Liner Edges Chip Before the Surface Wears Out?
A ceramic liner can reach a maintenance shutdown with much of its working face still intact. Yet the corners are chipped, pieces are missing along the joints, and the damaged area needs repair. For a mining transfer chute or a coal handling hopper, this is a useful clue. Before specifying thicker ceramic or changing the grade, check how the damage starts and where the material strikes. Follow the Damage Back to the Impact Point Start with close-up photographs of the chipped edges and a wider view showing the feed direction. Mark whether the damage follows the incoming side of the tiles, a change in the chute wall, or the boundary of a previous repair. Repeated contact at an exposed edge can initiate local cracks and break away small fragments while most of the ceramic face remains usable. Check for raised tiles, narrow cut pieces, and abrupt transitions. These details should be reviewed against the actual material path, including changes caused by buildup or variable feed. A damage photograph helps locate the problem; it does not establish the root cause by itself. Review the Support Beneath the Ceramic For bonded tiles, the review should include contact beneath the damaged area and the condition of the attachment. For a mechanically mounted panel, check how the backing plate sits against the equipment and whether the panel can move. Follow the approved installation procedure when investigating or correcting either arrangement. With rubber ceramic liners, the ceramic and rubber need to be assessed together. A 2021 study of ceramic-rubber impact protection found that tile dimensions and rubber properties affected the stresses in the ceramic. Its model also showed that adding rubber to an already adequate backing could offer little improvement when the highest stress came from the tile’s initial response to impact. [2] That makes a universal instruction such as “use thicker rubber” difficult to justify. The proposed construction needs to suit the impact conditions, installation space, and temperature. Consider ZTA After Reviewing the Construction ZTA is worth considering when repeated impact fracture remains a concern. It should be compared with suitable alumina grades for the same duty. In a 2023 laboratory study, ceramic samples underwent edge impact-abrasion tests with corundum particles or steel balls. ZTA25 performed best with corundum, while the tested 95% and 96% alumina grades performed similarly to ZTA25 under the steel-ball condition. [1] The ranking changed with the test condition. These results support reviewing representative impact-abrasion performance; they do not establish a service-life multiplier for a finished liner panel. Give the Supplier Evidence for the Next Selection A useful review starts with the damaged panel, its location, and the operating conditions. Alongside the drawing and required quantity, provide: Damage photographs: close-up and overview photographs showing damage and flow direction. Material information: handled material, normal particle size, and maximum lump size. Impact and loading conditions: drop height, throughput, and any recent operating changes. Operating environment: temperature, wet or dry conditions, and the existing liner construction. Service records: time in service or cumulative tonnage, where recorded. This gives the supplier a basis for deciding whether the next step is a different ceramic grade, a revised panel construction, or a change to the local lining detail. ELACERA provides alumina and ZTA ceramic liner options, including rubber ceramic composite panels. Send the drawing and photographs of the damaged area so we can review the proposed lining against the duty before confirming the replacement specification. https://www.ybnceramic.com/sale-55483328-rubber-ceramic-liners-for-mining-transfer-chutes-elacera.html Technical References [1] Varga et al. Impact-abrasive wear resistance of high alumina ceramics and ZTA. Wear, 522, 204700, 2023. [2] Herr et al. Ceramic-rubber hybrid materials – A way to sustain abrasive heavy impact applications. 13th European LS-DYNA Conference, 2021.
Cyclone Distributor Liners: Alumina or Silicon Carbide?
A cyclone distributor may need repair because of damage around an outlet while much of the body lining remains usable. When that happens, the next question is often whether the whole distributor should be upgraded from alumina to silicon carbide. Before changing the specification, establish where the lining fails and how the outlet connects to the body. A material comparison is more useful when it addresses the location that actually limits service life. Identify the Part That Sets the Maintenance Interval The feed distributor and the hydrocyclone body have different functions. The distributor divides the incoming slurry between cyclone feeds, so its outlet connections deserve their own lining review. During a planned inspection, map the damage against the drawing. Record whether it appears inside an outlet arm, around its entrance, along a ceramic joint, or at the incoming feed connection. Also distinguish gradual material loss from broken or missing lining. These observations help frame the investigation; they should be checked against operating records before a cause is assigned. What a Published Engineering Report Shows A 2018 HMA Wear Solutions report describes a gold-processing application in Central Queensland handling ball mill discharge. The existing alumina-lined distributor suffered premature failure where the outlet arms joined the body. The replacement used SiSiC outlet sections extending into the body, with radius plates protecting the junctions. Tightly fitted alumina remained in the body, and monolithic alumina cylinders at the inlet matched the upstream pipe bore. [1] This was a supplier-reported engineering project. Because material and construction changed together, it does not establish how much improvement came from either change separately. Compare Complete Lining Proposals For a replacement quotation, ask each supplier to show the proposed material arrangement on a section drawing. A quotation stating “silicon carbide lining” leaves several questions unanswered: Which components use silicon carbide, and which grade is proposed? Where does that material meet the alumina lining? What finished internal profile will be produced? How will the lining be supported and retained? Can the outlet sections be inspected or replaced individually? An all-SiC proposal and a mixed-material proposal should be compared against the same drawing, duty and acceptance requirements. The material name alone is insufficient to assess either construction. Define What a Successful Replacement Must Achieve The purchasing specification should state more than ceramic thickness. Confirm the required finished bore, connection dimensions, available installation space, and acceptable internal transitions. Provide the slurry characteristics, normal and maximum flow conditions, temperature, and known operating changes. Where service records exist, identify the component that required maintenance first and the condition of the surrounding lining at that time. This gives the supplier a clearer target than a general request for “longer life.” Start With the Worn Junction For a distributor with repeated outlet damage, the useful decision is whether a proposed lining addresses that junction while remaining practical to manufacture, install and maintain. ELACERA supplies alumina ceramic liners for hydrocyclone applications. For a distributor lining enquiry, send a marked-up drawing, the damage location, and operating information so the material and construction requirements can be reviewed together. https://www.ybnceramic.com/sale-53932773-high-wear-resistant-alumina-ceramic-liner-for-hydrocyclone-durable-efficient.html Technical Reference [1] HMA Wear Solutions. Increasing Wear Life of Cyclone Distributor. Engineering report WEA-CS-0025, August 2018.

2026

10/17

How Long Should Ceramic-Lined Slurry Pipes Last? Look Beyond Month
“This pipe lasted six months” is a useful maintenance record. On its own, however, it is an incomplete basis for comparing ceramic-lined slurry pipes. Two installations may operate for the same number of months while handling different quantities of material under different conditions. Before using service life to compare suppliers, establish what each pipe handled and how its condition was assessed. Record the Duty Behind the Service Period Keep the installation date and operating hours, but also record cumulative throughput wherever reliable data is available. State whether the tonnage represents wet slurry, paste, or dry solids. These quantities should not be used interchangeably. Alongside throughput, retain the material description, solids concentration, particle size information, flow conditions and temperature. Record significant process changes during the service period. A calendar interval becomes much more informative when it is attached to a defined operating duty. What a Field Study Can Tell Us A 2013 Kidd Mine paper reported inspections of a 487 m borehole lined with a ceramic-polymer composite after 3.48 million tonnes of paste throughput. Acoustic measurements indicated average lining wear of 0.92 mm per million tonnes of paste, compared with a design value of 1.1 mm per million tonnes. [1] Those figures describe that installation and lining system. They are not performance ratings for sintered alumina tiles, ceramic rings or another supplier’s pipe. The useful lesson for a purchasing review is the connection between measured condition, material throughput and a clearly identified installation. Agree on the Inspection Method Before Operation Ask what the proposed inspection will actually measure. An external ultrasonic reading of the steel shell should not be presented as a direct measurement of the remaining ceramic unless the method has been validated for that particular assembly. The Kidd Mine paper discusses internal inspection methods, including acoustic surveying and camera inspection. [1] Their suitability for another pipeline depends on access, geometry, lining construction, and the information required. A camera image may reveal visible damage without providing a reliable thickness measurement. Dimensional measurements also need a defined baseline and a method for locating repeat inspections. Track Local Damage Alongside Average Wear Create an inspection drawing with identifiable pipe sections and measurement positions. A practical record should include: Pipe or fitting identification and installation date Baseline dimensions and inspection method Inspection dates and cumulative throughput Repeat readings at defined locations Photographs or observations of local defects Repairs, replacements and operating changes Keep the original readings as well as the calculated results. This allows differences in measurement position or method to be investigated later. Report local damage separately from average wear. An average value can conceal a small area that needs attention before the surrounding lining does. Use the Records to Improve the Next Specification An observed wear rate can support inspection planning, but it should not automatically be treated as a constant rate for the rest of the pipe’s life. Agree on review and replacement criteria with the responsible engineer, considering lining condition, local defects and the pressure-containing steel assembly. For an ELACERA ceramic-lined pipe enquiry, provide the drawing, operating duty and available inspection records. This gives a stronger basis for reviewing lining thickness and construction than a request to match an unspecified number of months. https://www.ybnceramic.com/supplier-4257288-wear-resistant-ceramic-pipe Technical Reference [1] White, A., McGuinness, M. and Newman, V. Pipeline wear solution at Kidd Mine: energy absorbent ceramic composites. Paste 2013, pp. 559–566. DOI: 10.36487/ACG_rep/1363_43_White.

2026

10/17

Czy rurki ceramiczne można używać w temperaturze 400°C?
W przypadku przenoszenia popiołu lotnego w wysokiej temperaturze, jedno z pierwszych pytań jest zwykle proste: Czy rurka z ceramiczną podszewką może pracować nieprzerwanie w temperaturze 400°C? Odpowiedź nie może opierać się wyłącznie na ceramike aluminiowej. Ceramika aluminowa ma dobrą odporność na wysokie temperatury, ale rurka stalowa o ceramicznej podszewce jest kompletnym zespołem. W związku z tym nie można automatycznie uznać, że okładka, która działa dobrze w temperaturze normalnej, nadaje się do ciągłego użytkowania w temperaturze 400°C. Głównym problemem jest rozszerzanie cieplne Stal rozszerza się znacznie bardziej niż alumina ceramiczna, gdy jest podgrzana. Przy podwyższonych temperaturach ta różnica powoduje napięcie pomiędzy stalową powłoką a ceramiczną podszewką.Ciśnienie może być ważniejsze niż sama twardość ceramiki.. Jeżeli konstrukcja mocowania nie pozwala na taki ruch, może dojść do pęknięcia, rozluźnienia lub lokalnego oddzielenia wyściółki. Z tego powodu projektowanie urządzeń o wysokiej temperaturze powinno uwzględniać: Ciągła temperatura pracy Maksymalna temperatura Cykl ogrzewania i chłodzenia Prężnica i długość rur Wibracje Metoda mocowania Umiejscowienie łokci, trampek i innych urządzeń wysokoprężnych Należy przejrzeć cały system wyściółki, a nie tylko ceramiki. Temperatura kleju nie jest temperaturą ceramiki Innym powszechnym nieporozumieniem jest wykorzystanie zdolności temperatury ceramiki jako wartości temperatury całej rury. To nieprawda. Ceramika może wytrzymać znacznie wyższą temperaturę niż klej, warstwa buforowa lub inne materiały mocujące stosowane w zespole. Kiedy więc klient pyta, czy rurka z ceramiczną podszewką może pracować w temperaturze 400°C, musimy najpierw wiedzieć,jak ceramika zostanie zamocowana wewnątrz stalowej rury. W przypadku pracy przy wyższych temperaturach metoda mocowania i układ rozszerzania termicznego muszą być zwykle poddane oddzielnemu przeglądowi. Rurociągi i armatury nie powinny być traktowane tak samo Rury proste i łokieć nie doświadczają tych samych warunków mechanicznych i termicznych. Łokcie, t-shirty i reduktory mają zazwyczaj bardziej skomplikowaną geometrię i mogą również mieć bardziej poważne zużycie lokalne. Oznacza to, że wybrana metoda wyściółki dla rury prostej nie powinna być automatycznie kopiowana do każdego urządzenia. W przypadku systemów o wysokiej temperaturze popiołów lotniczych, przed potwierdzeniem ostatecznej struktury ceramicznej, zazwyczaj sprawdzamy równe rury, łokcie i specjalne armatury oddzielnie. Jakie informacje należy przekazać? W przypadku wstępnego przeglądu technicznego najkorzystniejszymi informacjami są zazwyczaj: Normalna temperatura pracy Maksymalna temperatura Czy temperatura jest stabilna czy cykliczna Materiał przenoszony Średnica rur i grubość ścian Kierunek i prędkość przepływu, jeżeli są dostępne Rysunek rury lub urządzenia Dzięki tym informacjom można bardziej realistycznie ocenić strukturę wyściółki, grubość ceramiki i metodę mocowania. W przypadku zastosowań o temperaturze 400°C nie chodzi tylko o:Czy aluminiowa ceramika wytrzyma 400°C? Lepsze pytanie brzmi: Czy kompletny układ rurociągowy o ceramicznej podszewce jest w stanie przetrwać rozszerzenie cieplne i warunki pracy w temperaturze 400°C? To jest punkt, który należy potwierdzić przed produkcją rury.
